5
mStation
™
2.1 Stereo Orb
Introduction
Thank you for purchasing the mStation™ 2.1 Stereo Orb. Your new audio system com-
bines great audio performance and user-friendly operation with cutting edge style.
Whether used with your Apple® iPod®, MP3 player or computer, the mStation Orb will
provide years of musical enjoyment.
We are committed to creating innovative audio products to meet your home and
desktop needs. To get the most from your new system, please be sure to read this User’s
Guide completely. It contains all of the necessary information to connect and operate
your system for maximum performance. Also, please take a moment to register your
product by lling out and returning the enclosed Warranty Card.
If you have any questions about the installation or operation of this product, please
contact Technical Support at 1-800-213-7232 or log on to www.mstationaudio.com.
Contents
Remove all of the components and accessories from the carton. Make sure all of the
items listed below are present:
mStation Orb™
Stereo Mini-plug Cable
Remote Control
User’s Guide
6 iPod Dock Cradles
Warranty Card
Docking Port Dust Cover
24 Volt Power Adapter
USB A/B Device Cable
AC Power Cord (region-specic)
If for any reason any of the items are missing or damaged, please contact Technical
Support at 1-800-213-7232.
Assembly
Dock Cradle Installation
The docking port on the mStation Orb™ is designed to support the following Apple
iPod models:
iPod video
iPod with dock connector
iPod nano
iPod photo
iPod mini
We have included six dock cradles to perfectly mate your particular model to the
mStation Orb™. Choose the cradle that matches the shape of your iPod. (See Detail A
of the diagram on page 4.)
If you will be using an iPod without a dock connector, such as an original iPod
or iPod shue, or another audio source with a headphone jack (stereo mini
plug), skip to the section titled “Line In Connections” on page 7.
With the slot centered over the dock connector, align the four pins of the dock cradle
with the corresponding sockets on the mStation Orb™ and rmly seat the cradle in the
docking port as shown in the illustration on page 4. The rim of the cradle should be
ush with the top of the control panel deck.
If you will be connecting an iPod nano to the dock of the mStation Orb™, make
sure to insert its dock cradle (labeled NANO) with the “scoop” towards the right
of the dock connector as shown in Detail A on page 4.
