MTD 549 - Page 15

15
Series 549
Ref.
No.
Part No. Part Description
1. 747-1161A Control Handle
2. 749-1092 Upper Handle
3. 747-04080 Grass Catcher Frame
4. 749-0928A Lower Handle
5. 720-0279 Wing Nut
6. 710-1205 Rope Guide
7. 710-1174 Carriage Bolt 5/16-18 x 2”
8. 664-04007 Grass Bag
9. 720-0284 Handle Knob
10. 746-1130 Control Cable 40”
11. 726-0240 Cable Ties
12. 714-0104 Hairpin Clip
13. 732-04090A Torsion Spring — RH
14. 732-04089A Torsion Spring — LH
15. 731-04134A Grass Bag Door
16. 732-1014 Torsion Spring
17. 747-0710 Hinge Pin
18. 732-0700 Wire Rod
19. 731-04998 Trail shield
20. 748-0377C Blade Adapter
21. 710-1257 Hex Cap Screw 3/8-24 x 2.5
22. 736-0524B Blade Bell Support
23. 17032A Chute Deflector Adapter
24. 742-0741 Blade: 21” Mulching
25. 712-0431 Flange Lock Nut 3/8-16
26. 15261C Height Adjustment Plate
27. 687-02077 Pivot Bar Assembly — RH
687-02076 Pivot Bar Assembly — LH
28. 732-0404 Spring Lever
29. 738-0507B Shoulder Screw
30. 720-0426 Spring Lever Knob
31. 710-0216 Hex Screw 3/8-16 x 0.75
32. 687-02074 Front Height Adjuster Assembly — RH
687-02075 Front Height Adjuster Assembly — LH
33. 687-02039 Pivot Bar Assembly — RH
687-02040 Pivot Bar Assembly — LH
34. 782-5002B Front Baffle
35. 710-0654A Hex Washer Screw 3/8-16 x 1.0
36. 731-04150 Rear Baffle 21” Rd.
37. 710-0286 Machined Screw 1/4-20
38. 710-1652 TT Screw 1/4-14 x.625
39. 710-04371 Hex Screw1/4-15
40. 712-04064 Flange Lock Nut 1/4-20
41. 787-01231 Deck 21”
42. 734-1987 Front Wheel: 8-Spoke Bar Gray 8 x 2
43. 736-0270 Bell Washer.265 ID x.75 OD
44. 687-02055 Hinged Mulch Plug Assembly
45. 731-04177 Side Discharge Deflector
46. 710-0599 Screw 1/4-20
47. 710-0514 Hex Cap Screw 3/8-16 x 1.0
48. 736-0451 Shoulder Washer.320 ID x.930 OD
49. 710-0703 Hex Carriage Screw 1/4-20
50. 712-0397 Wing Nut
51. 750-04162 Spacer.375 O.D. x.50 I.D. x 1.02”
52. 747-0996 Chute Door Pivot Rod
53. 734-04082 Rear Wheel: 8-Spoke Bar Gray 12 x 2
54. 687-02057 Handle Bracket Assembly — LH
687-02056 Handle Bracket Assembly — RH
55. 687-02033 Handle Bracket — RH
687-02031 Handle Bracket — LH
56. 732-0866 Spring Lever
57. 720-0312 Spring Lever Knob
Ref.
No.
Part No. Part Description
RH Right Hand
LH Left Hand
