MTD Series 430 - Page 19

19
Ref
No.
Part Number Description
1 747-1161A Blade Control Handle
2 749-1092A Upper Handle
3 747-04080A Grass Catcher Frame
4 749-0928A Lower Handle
5 720-0279 Wing Nut
6 710-1205 Rope Guide
7 710-1174 Carriage Bolt ,5/16-18 x 2
8 664-04007A Grass Bag - Black
664-04027 Grass Bag - Yardman
664-04034A Grass Bag - Gray
9 720-04072 Hand Knob
10 731-04177 Side Chute
11 726-0240 Cable Tie
12 710-0703 Carriage Bolt ,1/4-20
13 731-05865 Rear Discharge Door
14 747-0710 Hinge Pin
15 17032A Deflector Chute Adaptor
16 732-04090A Torsion Spring - RH
17 734-04215 Rear Wheel, 8 x 1.8, K2 Bar
734-2005A Rear Wheel, 8 x 2.125, Zag
734-1987 Rear Wheel, 8 x 1.8, Bar
734-2004A Rear Wheel, 8 x 2.125, Zag, BB
18 731-04150C Rear Baffle
19 710-0599 Screw, 1/4-20 x .500
20 787-01279 Deck - 21”
21 687-02055 Hinged Mulch Plug Assembly
22 782-5002B Front Baffle
23 748-0377C Blade Adapter, #6 x 2.15
748-04082 Blade Adapter, 25mm x 2.15
24 742-0741 Mulching Blade
25 710-1257 Hex Screw , 3/8-24 x 2.5
26 687-02338 Pivot Arm Assy RH (7” wheel)
687-02337 Pivot Arm Assy LH (7” wheel)
687-02337 Pivot Arm Assy RH (8” wheel)
687-02338 Pivot Arm Assy LH (8” wheel)
Ref
No.
Part Number Description
27 736-0524B Blade Bell Support
28 787-01290 Front Adjustment Plate
29 720-0426 Adjustment Lever Knob
30 732-0404 Spring Lever Assembly
31 736-0270 Bell Washer
32 734-04213 Front Wheel, 7 x 1.8, K2 Bar
734-2005A Front Wheel, 8 x 2.125, Zag
734-1988 Front Wheel, 7 x 1.8, Bar
734-2004A Front Wheel, 8 x 2.125, Zag, BB
33 710-1241 Screw, 1/4-15 x 1.000
34 746-1130 Control Cable 40”
746-1137 Control Cable 53”
35 738-04266 Shoulder Screw
36 731-05642 Trailshield
37 732-04089A Torsion Spring - LH
38 712-0397 Wing Nut, 1/4-20
39 747-04587 Rear Door Pivot Rod
40 732-04175 Spring Lever
41 687-02333 Pivot Arm Assembly - RH
687-02332 Pivot Arm Assembly - LH
42 710-1652 AB Screw
43 712-04065 Flange Lock Nut, 3/8-16
44 732-1014 Torsion Spring
45 710-0654A TT Sems Screw, 3/8-16 x 1.0
46 687-02099B Ht. Adj. Assy. Front LH (7” wheel)
687-02100B Ht. Adj. Assy. Front RH (7” wheel)
687-02075B Ht. Adj. Assy. Front LH (8” wheel)
687-02074B Ht. Adj. Assy. Front RH (8” wheel)
47 687-02270A Rear Handle Bracket Assy. - LH
687-02271A Rear Handle Bracket Assy. - RH
48 731-1506A† Front Cover
49 736-0504† Wave Washer
50 731-2626† Bail Cover - Black
731-04859† Bail Cover - Gray
51 731-0981A† Hub Cap
Model Series 430
† If Equipped
NOTE: Mower features/components vary by model. NOT all parts listed above and pictured on the previous page are standard
equipment.
