DIP Switch SW3 - Velocity Signal Processing
–
+
1
2
3
EXTERNAL BRUSHLESS
TAC
INTERNAL RESOLVER
TAC
SW3
R139
R138
13K
13K
1
2
3
4
5
6
7
8 9
10
11
12
13
14
15
16
C109
.022M
C92
.047M
C93
.1M
R137
51K
51K
R159
R158
100K
R157
200K
R156
390K
VEL
TP23
U39A
LM358
R154
R155
200K
REF– 3
2
1 REF+
R
A
8
50K
10K
CCW
