Action 14. Checking the oil level in the
intermediate support of the FDA car-
dan drive
Check the oil level in the intermediate
support. If necessary, add oil to the level
of the lower edge of the filler opening
closed with plug (1).
Action 15
*
. Turbocharger (MTZ-
900.3/920.3/950/950.3/952/952.2/952.3)
Check the tightening of the fastening
bolts of the turbocharger (1), exhaust
manifold (2) and exhaust pipe holder (3).
If necessary, tighten the bolts with the
torque of 35-40 N-m (3.5-4.0 kgf-m).
*
Perform M action after 250 hours of operation.
Action 16. Lubricating the hydraulic
cylinder joints of the steering trapezi-
um
Using a gun, grease the joints via oil
feeders (1) (two off) with the grease “Litol-
24” or recommended substitutes until it
appears outside.
FDA with bevel reducing gears
FDA with planetary redu cing gears
