Action 21
*
. Changing the oil in the en -
gine
• Warm up the diesel engine to normal
operating temperature (at least 70°C).
• Place the tractor on a flat area, stop
the engine and apply the parking
brake.
• Remove the cap (2) of the oil filler neck
and unscrew the drain plug (4).
ATTENTION: be careful to avoid contact
with hot oil.
Drain oil into waste storage tank.
• Place the drain plug (4) back and fill in
fresh motor oil through oil filler neck (1)
(М-8ДМ, М-8Г
2
, М-8Г
2К
in winter and
М-10ДМ, М-10Г
2
, М-10Г
2
к in summer
to the upper mark of the oil-measuring
probe (3).
• Refit the filler neck cap (2).
• Start the engine and let it run for 1-2
minutes.
• After 10 minutes from the moment of
stopping the engine, check oil level
with the probe.
• If necessary, add oil.
*
For supercharged diesel engines, change oil after
each 250 hours of operation.
