Action 51. Washing the primary
oil filter of the engine
• Loosen four clamps of connector
sleeves and remove the filter from oil
line located in front of the engine oil ra-
diator.
Wash the filter in diesel fuel and blow
it with compressed air in the direction
of the arrow on the filter body.
Replace the filter, paying attention to
its correct orientation in the oil line.
Tighten the sleeve clamps.
Action 52. Washing the engine breath-
er
• Unscrew the bolts (1) and remove the
breather casing (2).
• Remove the breather from the casing,
wash it in diesel fuel and blow it with
compressed air. Pour some motor oil
into the breather filter and letting the
oil to flow down, fit it back.
