Steering-Wheel-Mounted (Multifunction)
switch (1)
It ensures the switching-on of the turn
indicators, toggling the beam of the road
headlights (lower/upper beam), warning by
upper beam warning and horn beep.
Turn indicator
Turning the arm (1) up or down switches
on the right or left turning indicator, re -
spectively.
NOTE: After completing the turn of the
tractor, the arm (1) is returned automati -
cally to the neutral position.
Upper/lower beam
When the road headlights are switched on
by the switch (2), pushing the arm (1)
switches the “upper beam” o n and pulling
the same switches the “lower beam” on .
Pulling the arm (1) further from the “lower
beam” position towards the operator up to
the stop switches on shortly the upper
beam (n o n -fixed position) .
Horn beep
Pressing the arm (1) in axial direction
switches the beep on.
