Control lamps of the dashboard (dashboard 826-3805010)
1 – Reserved indicator (green)
2 – Reserved indicator (green)
3 – Reserved indicator (red)
4 – HPS emergency oil pressure. The
lamp (red) lights up when oil pressure in
HPS feeding system is below the allowa-
ble level.
5 – Air filter blocking. The control lamp
(orange) lights up when the maximum
allowed level of filter blocking is ex-
ceeded and it needs cleaning.
6 – Reserved indicator (blue).
7 – Rear axle differential locking control
lamp. The lamp (green) is on when
switching automatic differential locking
(ADL).
8 – Starting aid lamp: This orange con-
trol lamp is on when pressing the but-
ton of electric torch pre-heater (ETP).
After 30 s the lamp will start blinking,
indicating that diesel engine starting
system under cold conditions is ready
for operation.
9 – Reserved indicator (red).
1 0 – Reserved indicator (red).
