Multi 200 User Manual

2. CAUTION
● Before operating this instrument, familiarize yourself with all instructions outlined in this manual.
● Always check to make sure that the function switch is set to the position.
● When making measurements, use CAUTION as dangerous voltages may be present in normally
safe areas.
● To avoid electrical shock, use CAUTION when working above 60V DC or 25V AC rms. Such
voltages pose a shock hazard.
● Never make measurements with the battery cover OFF.
● Never fail to keep to the maximum tolerable input.
● Never operate this instrument if it gets wet, damp or has any liquid condensation build-up on any
part of the instrument.
3-1. General
Measuring Method:
Dual integration mode
Measuring Function:
AC load current
Display:
3.5 digit LCD max. reading of 1999
Over Range Indication:
Only max. digit “1” blanking
Maximum Indication:
1999
Low Battery Indication:
2.5V-2.7V: “+-B“ mark on LCD
Data Hold Indication:
“DH” mark on LCD
Sampling Time:
Approx. 2 times/sec.
Auto Power Off:
The meter is set to power off mode approx., 10 minutes after
the power switch on.
Limitation of Circuit Voltage:
Less than AC 600V
Withstanding Voltage:
AC2000V/1 minute max. (between the core of CT and rear
case)
Operating Temperature:
0~40℃ <80%RH(non-condensing)
Storage Temperature:
-10~60℃ <70%RH(non-condensing)
Power Supply:
LR44 or SR44 x 2
Power Consumption:
Approx. 5mW
Battery Life:
Approx. 50 hours(LR44)
Size
54(W)x170(H)x21(D)mm
Weight:
Approx. 100g
Accessories:
Batteries…………………..………….2
Instruction manual………………..…1
Soft case……………………….…….1
3-2 General CT Measurement
Range:
0~20A/200A (50/60Hz)
Ranging:
2 ranges manuals
Condition of Accuracy:
23℃±5℃, 80%RH max.
Range:
20A
200A
Min. Resolution:
10mA
0.1A
Accuracy:
±1.2%rdg ±5dgt
±1.2%rdg ±5dgt
Jaw Opening Capability:
φ33mm

Multi 200 Specifications

General

Measurement Parameters	DC Voltage, AC Voltage, DC Current, Resistance, Diode Test, Continuity Test
Type	Digital Multimeter
Diode Test	Yes
Continuity Test	Yes
Operating Temperature	0°C to 40°C
Power Supply	9V battery
AC Voltage Range	200V, 500V
DC Current Range	10A
Measurement Range	Depends on parameter
Accuracy	±(0.5% + 2 digits)
Display	LCD
