User Manual: PS020A DMX-controlled 3-CHANNEL Power Supply
V1.00 (06-2007) © Multiform, Leigh-on-Sea, UK 12
“P” DMX Preset Mode
If you want to run the pre-programmed patterns and scenes by an external DMX-
controller you can use the DMX Preset Mode. Press the MODE button (5) until the
display shows “P”, indicating operation in “P” (DMX Preset) mode. Set the DMX starting
address by simply using the UP/DOWN buttons (6/7). The chosen DMX-address comes
effective approximately 3 seconds later and will show up on the display (2) in
alternation to the “P”.
The unit receives DMX values on a packet of four channels and mirrors the received
data on the DMX output (13). If a DMX signal is present the DMX LED (3) will turn on.
The four channels control the unit as follows:
If DMX-value of channel 3 is lower than 50 the unit works with static colours:
DMX Channel Value Range Function
CH1 000-255 Colour choice from presets (see “C” mode)
CH2 000-255 Dimmer
CH3 000-049 Static colour mode active
CH4 000-049 Strobe off
050-255 Strobe (050=slow / 255=max. speed 23 Hz)
Colour presets can be activated by means of CH1 whilst the chosen colour can be
dimmed by weighting the colour balance with CH2. If the value of CH4 is above 50 the
unit is set to strobe mode. The strobe speed for any fixed colour chosen on the first
channel can be adjusted from zero (value <50) to 23 flashes per second (value 255).
If DMX value of channel 3 is equal or higher than 50 the unit works in pattern mode:
CH1 Pattern CH1 Pattern
000-015 Soft fade red-green 136-150 Hard switch green-blue
016-030 Soft fade green-blue 151-165 Hard switch red-blue
031-045 Soft fade green-blue 166-180 Hard switch red-yellow
046-060 Soft fade red-yellow 181-195 Hard switch candy-lime
061-075 Soft fade candy-lime 196-210 Hard switch pink-blue
076-090 Soft fade pink-blue 211-225 Hard switch turquoise-pink
091-105 Soft fade turquoise-pink 226-240 Hard switch red-green-blue
106-120 Soft fade red-green-blue 241-255 Hard switch red-yellow-green
121-135 Hard switch red-green -turquoise-blue-pink
DMX Value range Function
CH2
000-255 Dimmer
CH3
050-255 Chase speed
CH4
000-049 Strobe off
050-255 Strobe (050=slow / 255=max. speed 23 Hz)
User Manual: PS020A
DMX-controlled 3-CHANNEL Power Supply
V1.00 (06-2007) © Multiform, Leigh-on-Sea, UK 5
■ Functional advice
This unit is immune to the presence of electromagnetic disturbances – both conducted
and radiated - up to a certain level. Under peak conditions, the unit is classified to show
a “class C” performance criteria and may encounter temporary degradation or loss of
function which may need manual help to recover. In such case, disconnect the AC
power from the unit and reconnect it again to recover.
■ Environmental advice
This unit is build to conform to the ROHS standards and the WEEE
directive 2002/96/EC of the European Parliament and of the Council of
the European Union. Under these regulations, the product shall not be
discarded into regular garbage at the end of its life, but shall be returned
to authorized recycling stations.
■ Unpacking
Please check that the box contains the following items:
Main parts: 1 pcs. PS020A main unit
1 pcs. mains cable
1 pcs. operation manual
Accessory parts: 1 pcs. Mounting cover
2 pcs. Mounting screw
1 pcs. connection cable to panel
If any part is missing, please contact your dealer immediately for replacement.
Note: Your dealer may have chosen to pre-assemble this product with any suitable of
Multiform’s LS series passive RGB LED panels for you. In this case, the above
accessory parts have already been used during assembly.
■ Getting started: connecting/assembly
In case your dealer did not pre-connect/assemble the unit for you with any of
Multiform’s LS series passive RGB LED panels, you need to connect/assemble it
before use.
Risk of electric shock: Do not connect the mains cable before the
following steps are accomplished!
For assembly, there are two basic choices:
