Multiplex MULTIcharger LN-5014 User Manual

Multiplex USA • 12115 Paine St. • Poway, CA 92064 • www.multiplexusa.com
MULTIcharger LN-5014 # M92523 (06-05/REV1)
9. Screen displays
Displays during charging or discharging
Display after charge termination
END 030:00 00000
NC 100mA 10.75V
Pressing the ENTER button while this message is displayed returns you to the main
menu.
Display of current values
This information is available for the last battery charged if you hold the BATTERY TYPE
button pressed in for longer than three seconds, after a charge or discharge process.
You can switch between the three windows using the INC and DEC buttons.
If you do not press any button for longer than about three seconds, the screen
reverts to the normal display.
10. Error messages
INPUT BATTERY
VOLTAGE ERROR
Input voltage below 11.0 V or above 15.0 V
OUTPUT BATTERY
REVERSE POLARITY
Battery connected to the charger with reversed polarity
CHECK THE BATT.
OPEN CIRCUIT
Break in charge circuit
NO BATTERY
No battery connected to the charger’s output
OUTPUT CIRCUIT
PROBLEM
Internal error in charger
Programming flow charts for MULTIcharger LN-5014
Note: Flow chart for the Pb or Lead acid battery appears first due to space constraints in this manual
PB DISCHARGE
D=.050A
12Vpack
ENTER
INC
INC
DEC
DEC
DEC
INC
ENTER
PB CHARGE
C=3.0A 12Vpack
PB DISCHARGE
D=0.50A 12Vpack
BATT TYPE
PB CHARGE
C=3.0A 12Vpack
PB CHARGE
C=3.0A 12Vpack
BATTERY CHECK
WAIT PLEASE. . . .
CHG 0:00 00000
Pb + 3.0 1.200
PB DISCHARGE
D=0.50A 12Vpack
BATTERY CHECK
WAIT PLEASE. . . .
CHG 0:00 00000
Pb - 3.0
1.200
INC
INC
DEC
DEC
ENTER
ENTER
START
START
Œ
PB
INPUT = 12.00V
OUTPUT = 13.18V
ChgCAPA=00000mAh
DchCAPA=00000mAh
CHG PEAK = 12.00V
DCHG AVR = 13.18V
Battery
Voltage
Max.
Discharge
Current
1…5 1.00
6 0.83
7 0.71
8 0.63
9 0.55
10 0.50
11 0.45
12 0.41
13 0.38
14 0.35
15 0.33
16 0.31
17 0.29
5014 Discharge
Current
Capabilities
