13
HP Type Volts/Amps Hz RPM
Motor Voltage
(Factory)
Connected
Service Factor Motor Amps
Max
Liquid
Temperature
Single Phase Three Phase
115V 208V 230V 208V 230V 460V
3/4
Single
Phase
115/208-230
60 3450 230V
11.6 5.8 5.8
180˚F
1 16.6 8.5 8.3
1-1/2 23 12.5 11.5
2
208-230
-- 13 12
3 -- 18 17
3/4
Three
Phase
208-230/460 60 3450 230V -- -- --
2.6 2.8 1.4
180˚F
1 -- 3.6 1.8
1-1/2 5.4 5.2 2.6
2 6.8 6.6 3.3
3 -- 9.2 4.6
Motor info subject to change without notice, please consult motor nameplate.
HP Type Volts/Amps Hz RPM
Motor Voltage
(Factory)
Connected
Service Factor Motor Amps
Max
Liquid
Temperature
Single Phase Three Phase
115V 208V 230V 208V 230V 460V
2.5 Single Phase 230 60 3450 208/230V -- 15.7 16 -- -- -- 180˚F
2.5 Three Phase 60 3450 230/460 -- 8.75 4.35 180˚F
Motor info subject to change without notice, please consult motor nameplate.
HP Type Volts/Amps Hz RPM
Motor Voltage
(Factory)
Connected
Service Factor Motor Amps
Max
Liquid
Temperature
Single Phase Three Phase
115V 208V 230V 208V 230V 460V
5 Single Phase 230 60 3450 230V -- 27 24.5 -- -- -- 180˚F
5 Three Phase 208-230/460 60 3450 230V -- -- -- -- 14 7 180˚F
*5 Three Phase 230/460 60 3450 230/460V -- -- -- -- 17.2 8.6 180˚F
Motor info subject to change without notice, please consult motor nameplate. * Phase Conversion Compatible
PUMP SPECIFICATIONS
LP Series 3/4 HP - 3 HP
LP1502
LP3005
WIRING SIZE CHART
Motor
Rating
Circuit
Size
Fuse
Size
Full
Load
Amps
Copper Wire Size
Volts HP Phase KW 12 10 8 6 4 2
120
(1ø)
1/4
1
20
10
5.8
0.186
291
464
692
1171
1863
2350
1/3
1
20
10
7.2
0.246
230
365
546
924
1471
2338
1/2
1
20
15
9.8
0.373
171
272
407
689
1096
1742
3/4
1
20
15
13.8
0.559
130
207
310
524
834
1326
1
1
20
20
16
0.746
99
157
236
399
635
1009
1-1/2
1
30
25
20
1.12
128
192
325
515
822
240
(1ø)
1/4
1
20
5
2.9
0.186
1166
1853
2769
4685
7453
11850
1/3
1
20
5
3.6
0.246
920
1462
2186
3699
5884
9355
1/2
1
20
8
4.9
0.373
685
1090
1629
2756
4384
6970
3/4
1
20
8
6.9
0.559
522
829
1240
2098
3337
5305
1
1
20
10
8
0.746
397
631
944
1597
2540
4039
1-1/2
1
20
15
10
1.12
269
427
639
1081
1720
2734
2
1
20
20
12
1.49
259
411
615
1041
1656
2633
2-1/2
1
30
20
11.6
1.9
220
344
522
885
1407
2238
3
1
30
25
17
2.24
184
292
437
739
1176
1871
5
1
40
30
28
3.73
198
296
502
798
1269
Motor
Rating
Circuit
Size
Fuse
Size
Full
Load
Amps
Copper Wire Size
Volts HP Phase KW 12 10 8 6 4 2
208
(3ø)
1-1/2
3
20
10
6.6
1.12
530
843
1340
2131
3389
5385
2
3
20
15
7.5
1.49
407
648
1031
1639
2607
4145
2-1/2
3
20
15
9.0
1.9
346
551
876
1393
2216
3523
3
3
20
15
10.6
2.24
289
459
731
1162
1849
2939
5
3
30
25
16.7
3.73
181
289
459
730
1162
1847
240
(3ø)
1-1/2
3
20
10
6
1.12
641
1019
1522
2576
4098
6516
2
3
20
10
6.8
1.49
492
783
1170
1979
3148
5006
2-1/2
3
20
15
8.2
1.9
418
666
995
1682
2676
4255
3
3
20
15
9.6
2.24
354
563
841
1423
2264
3600
5
3
30
20
15.2
3.73
243
386
577
977
1555
2472
480
(3ø)
1-1/2
3
20
5
3
1.12
2693
4280
6396
2
3
20
5
3.4
1.49
2019
3210
4797
8116
2-1/2
3
20
10
4.0
1.9
1716
2729
4077
6899
3
3
20
10
4.8
2.24
1615
2568
3837
6492
10328
5
3
20
10
7.6
3.73
973
1547
2311
3911
6221
9891
Values are for estimating purposes only and may not meet NEC code. Design should be veried.
