16
PARTS BREAKDOWN
LP3005
ITEM SINGLE PHASE HORSEPOWER 5
MODEL NO. LP3005B
DESCRIPTION PART NO.
1 Motor, NEMAJ - 1 Phase MLP131641 1
▲
2
3
▲
4
5
6
Slinger, Washer
Shaft Sleeve
Mount Ring
Hex HD Cap Screws 3/8” x 3/4”
Gasket, Square Cut
Seal, Rotary W/Spring
Retaining Clip
MLPG005
MLP60010
MLP3300
MLPB909
MLPG003
PACSC185
MLP30001
1
1
1
4
1
1
1
7
8
9
▲
10
▲
Impeller, Brass “B” model
Flat Impeller Washer
Beveled Impeller Washer
Impeller Bolt - Hex HD Cap Screw 1/4” x 1”
Diffuser
Diffuser Bolt - Hex HD Cap Screws 5/16” x 1 1/2”
MLP3405
MLP3WASH
MLP3CONE
MLPB906
MLP3200
MLPB910
1
Part Retired, 2018
1
1
1
2
11
12
▲
13
▲
Gasket, Diffuser
Pump Body
1/4” Drain Valve
3/4” Priming Plug
1/4” Sensor Port Plug
MLPG004
MLP3100
MLP913
•
•
1
1
2
2
1
(•) Standard hardware Item ---- (▲) Not Shown ---- (*)3 Phase Only
