Muratec MFX-3595 User Manual

5-69
PCB TOS (TOC_TC)
1. Remove the Cassette [1].
2. Disconnect the connector [2].
3. Remove the shaft [3] and take out the Bracket TOS TC.
[
2
]
[
3
]
[
3
]
[
1
]
4. Remove one screw [4], then remove the PCB TOS [5].
[
4
]
[
5
]
