VJ-1624/1624W OPERATION MANUAL 4 Handling the printer
4-35
NOTE
• When a certain time has passed without opening Maintenance cover, Print head returns toward
the right side of the printer for protection. "Attaching instrument [ENTER]" is displayed.
Restart from the step 6.
8. Firmly pinch the tabs on both sides of the connector cap with your fingers, pull the connector cap
forward to remove it from Print head.
No. Name
1 Maintenance cover
No. Name
1 Connector cap
2Tabs
3 Print head section
1
1
1
2
2
3
To Next Page
