VJ-1624/1624W OPERATION MANUAL 3 Before using
3-33
9. Remove Cleaning fluid pack and IC chip card from High-capacity ink pack adapter.
NOTE
• When there is remaining Cleaning fluid pack and IC chip card, clarify the corresponding pack
and card, and store it as a set.
10. Install Ink pack and IC chip card to High-capacity ink pack adapter.
• Shake Ink packs 2 to 3 times lightly before installing them into High-capacity ink pack adapter.
11. Install High-capacity ink pack adapters (K, C, M, Y) in Ink cartridge slots on the back of the printer.
• Make sure that Ink packs are inserted into the correct Slots.
Match the ink color label with the ink color before inserting Ink pack.
NOTE
• Do not insert High-capacity ink pack adapter into Ink cartridge slot without attaching Ink pack.
The information of the remaining IC chip card will be rewritten and Ink pack will not be usable.
No. Name
1 High-capacity ink pack adapter
2 Ink cartridge slots
3 Ink color labels
1
2
3
To Next Page
