VJ-1324 OPERATION MANUAL Product overview
2.2 Names of parts and functions 31
(2) Display section
No. Name Color Status Description
9 Power lamp Blue Lamp
ON
Power ON.
Lamp
blinks
• Receiving and analyzing the data.
• Performing media initial operation.
Lamp
OFF
Power OFF.
10 Error lamp Orange Lamp
ON
An error has occurred.
Error content is displayed on the LCD.
Lamp
blinks
The remaining amount of ink is low.
Lamp
OFF
There is no error.
11 High lamp Green Lamp
ON
The head height is set to High.
Lamp
OFF
The head height is set to Low.
12 Low lamp Green Lamp
ON
The head height is set to Low.
Lamp
OFF
The head height is set to High.
13 Take Up lamp Green Lamp
ON
Media ejection mode is set to "Take-up".
Lamp
OFF
Media ejection mode is set to "Off" or "Auto cut".
14 Auto Cut lamp Green Lamp
ON
Media ejection mode is set to "Auto cut".
Lamp
OFF
Media ejection mode is set to "Off" or "Take-up".
15 Long lamp Green Lamp
ON
• Cleaning mode is set to Long.
• When the Normal lamp is also on, Cleaning mode is set to Short.
Lamp
OFF
Cleaning Mode is set to Normal.
16 Normal lamp Green Lamp
ON
• Cleaning Mode is set to Normal.
• When the Long lamp is also on, Cleaning mode is set to Short.
Lamp
OFF
Cleaning Mode is set to Long.
17 LCD display section — — Displays operation status of the printer or an error message.
