VJ-1617H OPERATION MANUAL Before using
3-87
NOTE
• When a certain time has passed without opening the maintenance cover, the print head returns
toward the right side of the printer to protect the print head. "Attaching instrument [ENTER]" is
displayed. Restart from the Step 7.
9. Firmly pinch the tabs on both sides of the connector cap with your fingers, pull the connector cap
forward to remove it from the print head.
10. Press the release buttons on both sides of spectrophotometer, install it to the connector at the print
head.
No. Name
1 Connector cap
2Tabs
3 Print head section
No. Name
1 Spectrophotometer
2 Release buttons
3 Print head section
4 Connector
1
1
2
2
3
4
1
1
2
3
