Maintenance VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL
306 6.1 Replacing consumable components
4. Open Front cover.
• Replace Flushing-box sponge in a short time.
Leaving Print head at the replacement position may result in clogging of Print head.
5. Lift Flushing-box sponge tab and unhook. Then, remove Flushing-box sponge.
• Do not spill waste fluid when replacing Flushing-box sponges.
If waste fluid comes into contact with Grid roller, it may damage its surface and
affect media feeding.
No. Name
1 Front cover
No. Name
1 Flushing-box sponge tab
2 Flushing boxes
To Next Page
