Handling the printer VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL
196 4.2 Media
• The initial adjustment value is saved.
• "PF2: Initial Change" is displayed on Operation panel.
5. Performs Confirm Print.
a. Press the [+] key or [–] key on Operation panel to select "PF3: Confirm Print".
b. Press the [Enter] key on Operation panel.
• "Feed Length: 250 mm" is displayed on Operation panel.
The length of media that is fed (feeding length) for confirmation adjustment printing is normally set at 250 mm.
If you increase the feeding length, the accuracy of the Media feed compensation improves.
To change the feeding length, press the [+] key or [-] key on Operation panel and change the set value.
c. Press the [Enter] key on Operation panel.
• "Printing" is displayed on Operation panel.
• Starts confirmation adjustment printing.
• When the Confirm Print is complete, the printer enters Normal.
d. After the confirmation adjustment printing, cut the media.
4.4.3 Cutting media
6. Measure the distance between the two pluses in the confirmation adjustment print using a ruler.
Then, confirm that the distance matches the feeding length when printing.
a. If the distance does not match the feeding length, follow the procedure from Step 1 to Step 5 and
readjust.
b. If the distance matches the feeding length, proceed to step 7.
No. Name
1 FeedLength
2 Media feeding direction
