my-PV AC-THOR User Manual

AC•THOR
®
/ AC•THOR
®
9s Operating instructions, version a0020806 38
Description of the data types:
Int16
Int16-nc
Int32
Int32-sw
Int32-nc
Int32-sw-nc
Float
Float-sw
16-bit integer value, two's complement representation
16-bit integer value, magnitude sign representation (1st bit = sign)
32-bit integer value, two's complement representation
32-bit integer value, two's complement representation, swapped words
32-bit integer value, magnitude sign representation (1st bit = sign)
32-bit integer value, magnitude sign representation (1st bit = sign), swapped words
32-bit float value
32-bit float value, swapped words
This control types are currently not approved for hybrid systems with battery storage.
With the settings "Adjustable Modbus TCP (Sunspec etc)", the IP address of the signal source
must not change during operation (eg by a DHCP router), otherwise the AC•THOR loses the control
signal.
When controlled by an inverter, a feed-in meter is required in the system. The query of the
inverter otherwise provides no data.
We ask for your understanding that we cannot do any binding support for third-party
products. For questions about third-party products, please contact the technical support of the
respective company.
Operation with battery may require additional control parameters. In this case, please contact
the technical support of my-PV.

my-PV AC-THOR Specifications

General

Power Range	0-3 kW
Input Voltage	230 V
Frequency	50/60 Hz
Category	Controller
Operating Temperature	-25°C to +60°C
Communication	Ethernet, Modbus
Phases	1-phase
Output Power	0-3 kW
Type	AC-THOR
