11
Put the bike on the double kick stand so it’s supporting itself.
The quick release lever can be found through the middle of the front wheel.
Simply slot the front wheel into place in the front fork making sure the discfits
into the brake caliper, then holding one side of the lever (the bolt side) rotate
the lever a few times to tighten the front wheel into place and close the lever
to secure the wheel. This lever closure part should be firm but not overly tight.
And the wheel should feel secure and not wobble.
1
2
The front wheel is attached with a quick release lever.
Front Wheel
Put the bolt into place from the rear wheel side and bolt it into the foot stand.
Then use the 2.5mm bolts and nuts to secure the 2 front parts on each side.
All these parts should be in the box with your charger for you.
This will require three bolts either side.
1
2
Left & Right Foot Plates
1
2
2
Mycle Quick Set Up
