AHG37
MAIN FEATURES:
■ Active Matrix Super Thin TFT – LCD Panel
■ Full Function OSD (On Screen Display) Control
■ Full Function Remote Control2 Composite Video Inputs
■ Built-In Wireless Headphone IR Transmitter
■ User Select 7 – Channel Wireless FM Modulator Control
■ Adjustable Viewing Angle
AHG37/ 1
SPECIFICATIONS:
■ Display:
■ Back Light:
■ Resolution:
■ Viewing Angle:
■ Color Configuration:
■ Video Input System:
■ Power Source:
■ Operating Temperature:
■ Storage Temperature:
■ Dimension:
■ Net Weight:
7" TFT – LCD 16:9 Wide Screen Format
Built-In CCFT
1440 (H) X 234 (V)
65º / 65º / 65º / 50º (Left / Right / Top / Bottom)
RGB Vertical Stripes
NTSC / PAL (Auto Switching)
DC 12V (Negative Ground)
32º F ~ 140º F
-4º F ~ 158º F
8.9"(W) x 5.7"(H) x 1.3" (D)
0.35 lbs.
AHG37&AGG7說明書 11/29/2005 1:04 PM 頁面 10
