Single Truss Container Shelter SS262010R-5(W8*L6*H3.0m)
Part Code
Description
Drawings
Q'ty
1
Top arch pipe
5
2
Middle bent arch pipe
20
3
Shoulder bent pipe
10
4
Purlins
20
5
Bracing pipe
12
6
Mount rail-1
2
6A
Mount rail-2
2
7
Mount rail-3
2
8
Tension pipe
2
9
connection plate for base rails
8
10
Angle seat
20
11
Corner Clamps for fixing base rails
4
12
Channel steel clamps
10
13
Φ60 clips with M10*50 bolt
24
