32 of 53
GT1175 (H105 Medium) Hurricane Quick Set-Up and Parts Guide www.NabcoEntrances.com
P/N C-00106 Rev 8-10-16
Two Way
Mode
OFF OFF - Both Sensors on Terminals 3 and 8 and the Holding Beam* on Terminal 4 will receive signals
while the door is closed or cycling.
Hold Open
Mode
ON ON - No acvaon needed. Door is held open.
Reduced-Open
Mode
- - ON Door will go to the reduced opening posion upon acvaon.
One-Way
Trac Mode
ON OFF - ● Only the Sensor on Terminal 3 will receive signals while the door is closed.
● The Sensor on Terminal 8 and the Holding Beam on Terminal 4 will be ignored while the door
is closed.
● During the door cycle both the Sensors and the Holding Beam will receive signals.
● The electric lock will be acve to prevent exterior entry.
Night Trac
Mode
OFF ON - ● No Sensor on Terminals 3 or 8 or the Holding Beam on Terminal 4 will receive signals while
the door is closed.
● Acvaon is only accomplished by switching M0 to Red (7).
● During the door cycle both the sensors and the Holding Beam will receive signals. The
electric lock remains locked except for acvaons from wall plates or card readers.
To Next Page
