34 of 53
GT1175 (H105 Medium) Hurricane Quick Set-Up and Parts Guide www.NabcoEntrances.com
P/N C-00106 Rev 8-10-16
1 24-4941-02 FHMS, 1/4-20 X 1", PHIL, TRILOBE, ZN
2 24-0014-02 HHCS, 1/4-20 X 3/4", ZN
3 24-0019-05 1/4" EXTERNAL STAR WASHER
4 24-13282-11 Clear ENDCAP, HEADER, 1175, RIGHT HAND, 204
24-13282-12 Dark Bronze ENDCAP, HEADER, 1175, RIGHT HAND, 313
24-13282-21 Clear ENDCAP, HEADER, 1175, LEFT HAND, 204
24-13282-22 Dark Bronze ENDCAP, HEADER, 1175, LEFT HAND, 313
5 24-0011-13 Zinc FHMS, 1/4-20 X 3/4", PHIL, ZN
24-0011-96 FHMS,1/4-20 X 3/4,PHIL
6 12-8233 DOOR STOP ASSY JAMB MOUNTD-SPECIAL
7 14-9078 BRACKET, DOOR STOP
8 24-0019-15 WASHER,INT.1/4
9 24-0021-14 HEX NUT, 1/4-20, ZN
10 14-9079 DOOR STOP ASSY, TRACK MOUNTED - 1175
11 24-0021-27 NUT, SQUARE, 1/4"-20, ZN
12 24-0014-30 HHCS,#14 X 3/4 SELF DR TP
13 24-9022 BRACKET, END CAP - LOWER
14 14-11741 POWER SUPPLY, DS-150NA/U30
15 24-0021-21 NUT, WHIZLOCK, 3/8-16, ZN
16 24-14454 BRACKET, MOUNTING, FRONT, DS150
17 24-11327 OPERATOR - DS-150 NA
18 24-9027 IDLER TENSIONER BRKT (Assy is P/N 215990
19 24-0014-28 HHCS,3/8-16 X 2 3/4"
20 24-0021-15 HEX JAM NUT 3/8"-16
21 21-5990 IDLER BELT TENSIONER ASSY
22 22-9026 WELDMENT, IDLER - 1175
23 11-11701 IDLER PULLEY ASSEMBLY
24 24-0431 RING, RETAINING
25 22-9210 IDLER ASSY
26 24-0019-05 1/4" EXTERNAL STAR WASHER
27 24-0014-15 HHCS, 1/4-20 X 3/4, HWH, TRI-LOBE, ZN
28 14-11871 BRACKET, BELT,1175
29 14-11870 SPACER, BELT CLIP, 1175
30 24-11493 CLIP, BELT
31 24-11327 OPERATOR - DS-150 NA
32 24-11329 BRACKET, MOUNTING, REAR, DS150
33 14-0795 TIMING BELT 1/2" PITCH X 3/4" WIDE
34 14-2279-05 PILE WEATHERING, BLK, .45 TALL, W/ ADHES
35 24-4941-14 FHMS,PHIL,8-32 X 5/8" TYPE F
24-4941-20 FHMS,PHIL,8-32X5/8" TYPE F BK ZK
36 14-9199 NAMEPLATE, ADHESIVE BACKED
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
30
29
28
27
26
25
24
23
22
36
35
34
33
32
31
