Nabtesco CONPAL - Page 18

81-SS30048a
- 16 -
Figure 14
F
igure 15
Figure 16 Figure 17
Put three juts on the tire to
inset ditches on the wheel
body.
CAUTION
The rubber tire has three (3) juts inner side
to be fit to the wheel body.
Push like flipping the tire from the
wheel.
