Specifications
nap v175
Power output
Continuous, 8 ohms 50 watts per channel
Channels Three
Voltage gain +29dB
Frequency response -3dB @ 3Hz & 50kHz
Input impedance 18 kilohms
Mains supply 100V. 115V. 230V - 50/60Hz
Case size (H x W x D) 70 x 432 x 301mm
mains
input
power
to a/v processor
ch 1
nc
ch 2
-ve
Socket 2
centre
nc
nc
-ve
Socket 1
+- -+ -+
speaker
ch1, left
speaker
centre
speaker
ch2, right
1 2
14.1 rear
14.0 nap v175 connection diagram
