9
to preamplifiermains inputpower
stereo
freq
scan
preset
•
•
•
•
down up mode mono
note
The RC5 input is designed to accept external control signals for multi-room applications. Contact your dealer
for further information on its use.
The nat 05 features various technologies to reduce microphonic effects, in particular a compliant mounting
for the main circuit boards and the din sockets on the rear. Some movement of the board and sockets when
connecting/disconnecting is normal.
ch1
nc
nc
-ve
ch2
nat 05 output
Specifications
nat 05
Tuning Range (UK) VHF/FM 87.5 - 108MHz
(Tuning range regional variants set internally)
Preset Memory 99 stations
Output Level 700mV per channel
at 100% modulation
Mains Supply 100V, 115V, 230 V 50 or 60 Hz
CaseSize (H x W x D) 58.4 x 432 x 301mm
nat 05 front
nat 05 rear
75 ohm FM aerialRC5 input
