6. SPECIFICATIONS AND DIMENSIONS
6 - 1 Speci¿cation of the CONTROLLER
Product Name E3000 CONTROLLER
Model NE
211
Input Voltage AC100 - 240V, 50 / 60Hz, 1PHASE, 1.8A
Output AC
33V, 0-1KHz, 3 PHASE, 2.4A
Speed Range
1,000 - 80,000min
-1
(rpm) *Note 1
Over Voltage Category Ⅱ
Short Circuit Current Rating 63A
Pollution Degree Class
2
External
Control Signal
Input
Signal
Input : Digital
9 (Photo Coupler)
Analog
1
Output
Signal
Output : Photo Coupler 1, MOS Relay 9
Relay Contact 2, Analog 3
Protection Function
Excess Current, Over Voltage, Motor Sensor Malfunction, CONTROLLER
Overheat, Brake Circuit Trouble, Rotor Lock, Low Air Pressure, Torque Over
Load, Communication Interception, External Control Signal Error, Incompatible
Motor, Over Speed, Emergency Stop Error, Internal Memory Error
Weight
2.8kg
Dimensions W
88 x D138 x H238 mm
Operation
Environment
Temperature 0 - 40
°
C
Humidity MAX.
75% (No condensation)
Atmospheric
Pressure
800 - 1,060hPa
Transportation
and Storage
Environment
Temperature -10 - 50
°
C
Humidity
10 - 85 %
Atmospheric
Pressure
500 - 1,060hPa
Height above Sea Level Less than
2000m
* Note 1 : Motor Speed Limited Area
Motor Speed limits depend on the Motor Model. Before using it, check the speci¿cations of the motor and the motor spindle.
Since CONTROLLER will automatically recognize the motor types, there is no need to adjust the maximum rotation speed
based on the motor model.
・FOR EM-3080J MOTOR AND HES810 SYSTEM USERS
This motor / spindle is designed to machine at min
-1
(rpm) 's between 20,000 and 80,000min
-1
(rpm) only.
The
1,000 to 19,000min are for warm-up purpose only.
Do not machine at a Speed of less than
20,000min
-1
(rpm).
・ Control limits motor speed from 1,000 to 60,000 min
-1
(rpm) for EM-3060, EM-3060J, EM30-S6000, EM25-S6000 and
EM
20-S6000.
・Control limits motor speed from 1,000 to 50,000 min
-1
(rpm) for EM25N-5000 and HES510.
・Control limits motor speed from 1,000 to 32,000 min
-1
(rpm) for EM-3030J, EMA-3020K and EMA-3020S.
・Control limits motor speed from 1,000 to 30,000 min
-1
(rpm) for EM-3030T-J, EM-3030T-J-2M.
CAUTION
・ The brushless motor " EM-3030T-J / EM-3030T-J-2M " should be connected to the Applicable
CONTROLLER (Refer to " Table. 2 Identifying the Applicable CONTROLLER ").
If the brushless motor " EM-3030T-J / EM-3030T-J-2M " connected to non applicable
CONTROLLER, brushless motor " EM-3030T-J / EM-3030T-J-2M " will not rotate and Error " EL "
(Incompatible Motor) will be displayed on the Digital Speed I
ndicator, indicating a " Detection of
unsafe operating conditions " of the CONTROLLER.
