NAMCO MARIO KART User Manual

Page 79
3. Remove the Play Panel. (see 7-4 page 65)
4. Remove the Steering Assembly. (see 7-8 page 71)
5. Remove 4off Security screw (M5x12) and remove the Monitor Surround.
6. Remove 4off Security screw (M5x12) and remove the Top Arm.
7. Remove the 2off Security screw (M5x12) and remove the Bottom Arm.
Monitor Surround
Security screw (M5x12)
Top Arm
Bottom Arm
Security screw (M5x12)
Security screw (M5x12)
