Preload adjustment: you can adjust it by the lock nut under the
suspension spring. Screw it in for more hardness when starting the
rebound, or unscrew it for less hardness when starting the rebound.
Rebound adjustment: use the red ring on the top of the spring (see
attached photo). It adjusts the speed at which hydraulic oil moves as
damping.
You can adjust in two different ways:
S refers to slower hydraulic displacement, which is more difficult felling.
F refers to a faster hydraulic displacement which means a feeling of solfter.
ZOOMER SUR LA VIS ROUGE
How to adjust the suspensions
Maintenance of the scooter
ZOOMER SUR LES FREINS
How to adjust the breaks
1) please check if the disc is well balanced
2) please check if the disc pad is in the well condition
with enough thickness to provide the braking power
needed
3) please adjust the brake pad postion via the two srews
on the caliper
IMG 9220
IMG 9169
