NANO Q - Camera Controls and Interface Details; Button Layout and Port Identification

17
18
19
20
8 - microUSB port
9 - HDMI port
10 - GPS contacts
11 - POWER button
12 - MODE button
13 - INDICATOR button
14 - LED indicator
15 - 1.5" TFT screen
16 - UP button
17 - OK button
18 - DOWN button
19 - microUSB port
20 - AV-out port
APPEARANCE
15
16
8
9
7
10
11
12
13
14
1
