Introduction
7
NAPIER TURBOCHARGER
TYPE NA.295
SPECIFICATION
NA.295
Type
Max. Permissible
Speed ( R.P.M. )
Pressure Ratio
4:1
Max. Turbine
Inlet
Temperature
SEE
TURBOCHARGER
TYPE PLATE FOR
DETAILS
Weight
510 Kg.SEE TURBOCHARGER
TYPE PLATE FOR
DETAILS
approx.
NAMEPLATES
The turbocharger has the type of plate shown. This plate is mounted on the main casing. The
information shown on this name plate is explained overleaf.
Example of the Turbocharger nameplate
JH295
3EIL 72A 114 K
31,000
650
1000
