Napoleon PRO285X Instructions

36
www.napoleongrills.com
N415-0437CE-GB-DE OCT 23.17
Item Part # Descripon
1 N325-0085-SS1SG cart handle x
2 N120-0023 nylon cap x
3 Z570-0036 1/4-20 x 7/8” screw x
4 N325-0086-SS1SG cart shelf handle x
5 N120-0022 le self cap x
6 N120-0021 right shelf cap x
7 N570-0013 #8 X 5/8” screw x
8 N590-0237 scissor cart shelf x
9 N570-0076 #8 x 1/2” screw x
10 N570-0111 #14 x 1 1/4” screw x
11 N010-0804-SS1SG front cart beam x
N160-0017 ex line clip x
12 N010-0805-SS1SG rear cart beam x
13 N525-0047-BK1SG sliding track rail x
14 N530-0032 regulator hose DE x
N530-0033 regulator hose NL x
N530-0037 regulator hose UK x
N530-0046 regulator hose CZ x
N530-0034 regulator hose DK x
N530-0034 regulator hose NO, FI, ES x
N530-0038 regulator hose FR x
N530-0035 regulator hose SE x
N530-0036 regulator hose IT x
N530-0044 regulator hose PL x
N530-0043 regulator hose RU x
15 N080-0356-BK1SG hose mount ng adapter bracket x
16 N570-0086 #14 x 1/2” screw x
17 N135-0045-BK1HT base x
18 N570-0104 10-24 x 3/8” screw x
19 N475-0319 control panel x
20 N010-0825 manifold 50mbar (DE) x
N010-0773 manifold 30mbar (CE) x
21 N570-0078 10-24 x 3/8” screw x
22 N585-0089-BK1HT control panel heat shield x
23 N380-0020-RD control knob x
24 N200-0109-BK1HT right leg cover x
25 N200-0108-BK1HT le leg cover x
26 N710-0079 drip pan x
27 N010-0821 le drip pan bracket x
28 N010-0822 right drip pan bracket x
29 N570-0073 1/4-20 x 3/8” screw x
30 Z570-0033 10-24 x 12mm screw x
31 N100-0047 right burner x
32 N100-0046 le burner x
33 N655-0158 le boom support handle x
34 N655-0159 right boom support handle x
Parts List

Napoleon PRO285X Specifications

General

Brand	Napoleon
Model	PRO285X
Category	Grill
Language	English
