NARCO AVIONICS MK12D+
2 8/99
Item Order Number Description Accessory Part No.
1
2
3
4
5
6
7
8
03118-0317
03118-0318
03118-0319
03118-0320
03118-0321
03118-0322
03118-0323
03118-0324
MK-12D+ 14V (without GS) with:
Tray
Installation Kit
MK-l2D+ 14V (with GS) with:
Tray
Installation Kit
MK-l2D+ 28V (without GS) with:
Tray and Installation Kit
MK-l2D+ 28V (with GS) with Tray and Installation Kit
MK-l2D+ 14V Radio only (without GS)
MK-l2D+ 14V Radio only (with GS)
MK-l2D+ 28V Radio only (without GS)
MK-l2D+ 28V Radio only (with GS)
01372-0106
03118-0500
01372-0107
03118-0500
Table 2.1 Units and Accessories Supplied
Item Order Number Description Accessory Part No.
1
2
3
4
5
6
7
03749-0300
03749-0303
03749-0301
01372-0106
01372-0107
56912-0001
03749-0304
Indicator, ID824 TSO (No G/S-sine/cosine OBS)
with : Installation kit
Indicator, ID824A TSO (No G/S-sine/cosine OBS)
with : Installation kit
Indicator, 1D825 TSO (w/GS-sine/cosine OBS)
with : Installation kit
Tray MK12D (w/o GS)
Tray MK12D (w/GS)
Key, Spring Release
Indicator, ID825A TSO (w/GS - sine/cosine OBS)
with : Installation kit
03749-0500
03749-0500
03749-0500
03749-0500
Table 2.2 Optional Available Accessories
Item Part Number Description 03118-0500
1
2
3
4
5
6
7
8
41407-0002
56912-0001
50043-0001
50042-0001
66516-0010
50436-0001
57704-0002
84536-0704
Pin, Terminal, Gold Plated (72 contacts)
(Contact, Individual, Crimp Type Order
No. - 41407-0001)
Key, Spring Release
Shim, Side Rail Tray
Tool, Tray Side Rail Spacing
Fuse, 1/2 Amp (F2601 or F2602). Not used
for installation. Fuses provided are
spares for the 5 and 16V A+ lines located
on the Main PC Board.
Tool, Vertical Spacer, MK-12D
Heat sink
Screw, Mach., 4-40 x 5/16
1
1
2
1
2
1
Table 2.3 Installation Kit's Parts List
