National Instruments NI 6251 User Manual

Appendix A Device-Specific Information
© National Instruments Corporation A-107 M Series User Manual
NI 6259
The following sections contain information about the
NI PCI/PCIe/PXI/PXIe-6259, USB-6259 Screw Terminal, USB-6259
BNC, and USB-6259 Mass Termination devices.
NI PCI/PCIe/PXI/PXIe-6259
NI PCI/PCIe/PXI/PXIe-6259 Pinout
Figure A-44 shows the pinout of the NI PCI/PCIe/PXI/PXIe-6259. The I/O
signals appear on two 68-pin connectors.
For a detailed description of each signal, refer to the I/O Connector Signal
Descriptions section of Chapter 3, Connector and LED Information.
Note M Series devices may be used with most E Series accessories. However, some
E Series accessories use different terminal names. Refer to the M Series and E Series
Pinout Comparison section of Chapter 3, Connector and LED Information, for more
information.
