National Instruments PCI-8361 User Manual

1-8 | ni.com
Chapter 1 Introduction
Figure 1-9. PXI-8368 (157298x-02L) Block Diagram
Figure 1-10. PXIe-8360 (194402x-01L) Block Diagram
Note The PCI Express switch on the PXIe-8360 also supports dual link mode,
which will merge the links to the chassis backplane into two Gen 1 x8 links instead
of four Gen 1 x4 links.
PCIe-to
PCI
Bridge
ID Device
PCIe Gen 1 x1
Function 0
Function 2
MXI-Express x1
Fiber Optic
PCI
PCIe Switch
PCIe-to-
PCI Bridge
SMBUS
Master
PCIe Gen 1 x4
PCIe Gen 1 x1
MXI-Express x1
Copper
PCIe Gen 1 x4
PCIe Gen 1 x4
PCIe Gen 1 x4
