334 ENGINE ELECTRICAL
Special Torque
Table 44 Engine Electrical Special Torques
ECM / IDM mounting bolts (2), M8 x 45 20 N·m (15 lbf·ft)
ECM / IDM mounting stud bolts (2), M8 x 45/19 20 N·m (15 lbf·ft)
Engine coolant temperature (ECT) sensor 15-20 N·m (11-15 lbf·ft)
Engine oil pressure (EOP) sensor 9-14 N·m (79-124 lbf·in)
Engine oil temperature (EOT) sensor 15-20 N·m (11-15 lbf·ft)
Injection control pressure (ICP) sensor and Brake Control (BCP) sensor 20-30 N·m (15-22 lbf·ft)
Intake Manifold Air Pressure (MAP) sensor 10-20 N·m (88-176 lbf·in)
Intake Manifold Air Temperature (MAT) sensor 10-20 N·m (88-176 lbf·in)
EGES-265-2
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
© 2009 Navistar, Inc.
