76
NBB Controls +
Components
GmbH
Transmitter Nano-L SMJ 7,2 V
Commissioning
> Operating voltage 7.2 V
Insert the battery in the battery compartment for commissioning. For removal, press in the locking pin to
unlock and slide out the battery.
If the NBB radio control system won’t be used for a long period of time, it is strongly recommended
remove the battery from transmitter and charge the battery approx. every 4 weeks. This prevents
deep discharge of the battery and enhances its service life.
Safety equipment
> Safety equipment in the NBB radio control system
– EMERGENCY STOP or STOP function
– Zero position interlock
– Addressing each transmitter using a unique Binary bit code combination
– Rubber sleeves to protect the switch
Please check the sleeves and the housing for breaks and cracks each time before commissioning the
transmitter. Contact your service team if necessary. Non-observance can cause malfunctions and water
damage.
1. Press in the locking pin
2. Slide out the battery
Charge the rechargeable battery completely before initial use.
Please refer to the technical documents for the exact design.
