NBB Controls +
Components
GmbH
Receiver Compact-V 9600 Baud
Receiver Compact-V 9600 Baud
Operating ambient temperature – 20 °C to + 70 °C
Protection class IP 65
Receive frequency range See nameplate
Data security Addressing each receiver by a separate, unique Binary bit combination >16 million options
Safety EMERGENCY STOP with self-test, Restart lockout in the event of a faulty EMERGENCY STOP relay
Contact load of EMERGENCY STOP relay Max. 4 A / 250 V AC
Contact load of relay Max. 6 A, shortcircuit-safe
Power consumption < 4 VA / 12 DC, < 3 VA / 24 V DC, depending on the number of active relays
Supply Please refer to the technical documents.
Weight Approx. 1,500 g
Measurements (L x W x H) 172 x 70 x 191 mm
Technical data
