NBB HyPro-8 - Page 32

1 - 1
1
CONNECTING PLAN CAN CABLE TRANSMITTER - RECEIVER
Serial no.:
Cable length:
~ 10m
Model:
Cable loop-no.:
3.400.7022 (4 x 0,75 mm²)
Producer:
Plug transmitter:
3.910.1032 (male)
Date:
26.07.2021
Plug cable transmitter side:
3.910.1034 (female)
Name:
J. Rittmann
Plug receiver:
3.960.1033 (female)
Plug cable receive side:
3.960.1030 (male)
RECEIVER
CONTROL CABLE
TRANSMITTER
Function
Pin-no.
Pin-no. /
Wire-colour
/ Pin-no.
Pin-no. /
Function
8-36 V/DC
2
2
/
GY
/
1
1
/
8-36 V/DC
CAN High
5
5
/
BK
/
6
6
/
CAN High
CAN Low
4
4
/
BN
/
5
5
/
CAN Low
GND
8
8
/
YE/GN
/
7
7
/
GND
Power supply + V/DC from receiver
To programing the receiver, is only practicable, when the control cable is disconnect.
