NCR 7772-1516-8801 - Retail I;O Ports

2-16 Hardware Installation
I/O Ports
Retail I/O
The following are the default I/O ports for the NCR CX7 All-in-One POS (7772) with a
Retail I/OBase.
Callout Port Name
1 Cash Drawer
2 USB24V
3 USB12V
4 24V Power In
5 LED
6 USB-C
7 LANOut
8 LANIn
9 DB9 Serial
10 DisplayPort
11 Dual USB 3.0
12 RJ50 Serial
