technical specifications
MICROPHONE
Transducer Type: Proprietary 24 mm condenser
capsule, internally shockmounted
Polar Pattern: Selectable – Mono (cardioid), Stereo
(XY), Wide Stereo (Blumlein), or Focused Stereo (M/S)
Frequency Response: 20 Hz – 20 kHz
Sample Rate/Bit Depth: 96 kHz/24 bit
Sensitivity: 16.0 mV/Pa at 1 kHz (1 Pa = 94 dB SPL)
Maximum SPL: 128 dB SPL (0.5% THD)
S/N Ratio: 98.0 dB-A (IEC 651)
HEADPHONE AMPLIFIER
Impedance: 16 ohms
Power Output (RMS): 100 mW
THD: 0.05%
Frequency Response: 20 Hz – 22 kHz
S/N Ratio: 90.0 dB
5
Noise Level: 14.0 dB-A (IEC 651)
Dynamic Range: 98.0 dB (@ 2.5k ohms)
Power Requirement: 5V USB
Weight: 4.2 lb (1.9kg)
This Beecaster Capsule Frequency Chart is an accurate representation of the mic’s response, but how the microphone reacts in a particular application will
vary greatly depending on various conditions—room acoustics, distance from the sound source (proximity), instrument tuning, microphone cabling,
and more. For an artist or engineer, these internal and external variables create the basis of the final sound.
