8
Controls –continued
BRIGHTNESS
Adjusts the overall image and background screen brightness.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO CONTRAST (Analog Input Only)
Adjusts the image displayed for non-standard video inputs.
AUTO ADJUST (Analog Input Only)
Automatically adjusts the Image Position, H. Size and Fine setting.
LEFT/RIGHT (Analog Input Only)
Controls Horizontal Image Position within the display area of the LCD.
DOWN/UP (Analog Input Only)
Controls Vertical Image Position within the display area of the LCD.
H. SIZE (Analog Input Only)
Adjusts the horizontal size by increasing or decreasing this setting.
FINE (Analog Input Only)
Improves focus, clarity and image stability by increasing or decreasing
this setting.
COLOR CONTROL SYSTEMS
Four color presets (9300/7500/6500/USER) select the desired color
setting.
COLOR RED
Increase or decreases Red. The change will appear on screen.
COLOR GREEN
Increase or decreases Green. The change will appear on screen.
COLOR BLUE
Increase or decreases Blue. The change will appear on screen.
TOOL
Selecting TOOL allows you to get into the sub menu.
FACTORY PRESET
Selecting Factory Preset allows you to reset all OSM control settings
back to the factory settings. The “1 <-> 2 RESET” button will need to
be held down for several seconds to tage effect. Individual settings
can be reset by highlighting the control to be reset and pressing the
“1 <-> 2 RESET” button.
