English-15
English
SOUND INPUT
This function selects AUDIO INPUT, HDMI or DISPLAYPORT.
NOTE: According to the screen type, you can change which audio input signal is routed through the built-in speakers.
1 screen (MULTI PICTURE is OFF): Outputs the audio signal from HDMI, DisplayPort or the audio from the input
audio jack (AUDIO INPUT).
Split screen (MULTI PICTURE is ON): Outputs the audio signal that is associated with the adjustable screen’s video
signal (HDMI or DisplayPort) or the audio from the input audio jack (AUDIO INPUT) on the back of the monitor (right
side of display below USB port).
NOTE: The split screen type and adjustable screen is shown in amber colored.
Example: In case of slecting the 3 divided and the left screen.
Outputs the audio signal of the left screen’s video signal.
The adjustable screen is shown like below in SOUND INPUT:
2 split screen
LEFT RIGHT
3 split screen
LEFT CENTER RIGHT
LEFT TOP-RIGHT BOTTOM-RIGHT
TOP-LEFT BOTTOM-LEFT RIGHT
4 split screen
TOP-LEFT BOTTOM-LEFT TOP-RIGHT BOTTOM-RIGHT
VIDEO DETECT
Selects the method of video detection when more than one video inputs are connected.
FIRST: When current video input signal is not present, then the monitor searches for a video signal from the other
video input ports. If the video signal is present in another port, then the monitor switches the video source input port
to the new found video source automatically. The monitor will not look for other video signals while the current video
source is present.
NONE: The monitor will not search the other video input port unless it is turned on.
MULTI PICTURE
“ON” activates MULTI PICTURE (split screen) function (see page 24).
