NEC Display Solutions of America, Inc.
NP310/NP410/NP510 Installation Guide
Ceiling Mounted and Desktop Rev 1.1
www.necdisplay.com NP310/NP410/NP510 Page 4 of 6
Cabinet Dimensions (continued)
The following drawings show the cabinet dimensions.
Dimensions are in inches. For millimeters multiply by 25.4.
Lens Center
3 - M4*8 Max
for Ceiling Mount Kit
Intake
Exhaust
Filter
To Next Page
