PARTS DIAGRAM
§§
è
Parts List
LOC. PART NAME PART CODE SPECIFICATION REMARK
B01 COVER UNDER 3611402700 PP
B02 PLATE UPPER 3614514900 PP
B03 COVER B 3611414010 372x508x0.4t, SGCC
B04 HOLDER SUPPORT 3613010300 FRPP, B
B05 HOLDER SUPPORT 3613010200 FRPP, FL
B06 HOLDER SUPPORT 3613010100 FRPP, FR
B07 HANDLE CABINET 3612603300 PP
B08 CABINET 3610808100 1740.2x767.4x0.6t
B09 SARNESS OUTER 3610068700 50/0.18 GREEN ST710480-2 EARTH
B10 BASE U
3610311000 PP 5510, 5520, 6010, 6020
3610311900 PP 5511, 5521, 6011, 6021
B11 FOOT 4509D10020 BUTYL RUBBER
B12 LEG ADJUST AS 3617702200 DWF-5591DPN
B13
HOSE DRAIN O 3613217800 PE-LD PUMP
HOSE DRAIN O AS 3613213500 EVA L=950 N-PUMP
B14 GUIDE DRAIN HOSE 3612502300 PP PUMP
B15
CLAMP HOSE O 3611202200 HSW-3 PUMP
CLAMP 3611201000 HSW-3, MFZN D36 N-PUMP
B16 COVER PUMP 3611405320 PP PUMP
3963514000 AC 220~240V/50Hz
B17
MOTOR SHADED 3963514010 AC 220V/60Hz
PUMP
POLE 3963514020 AC 110V/60Hz
3963514030 AC 127V/60Hz
B18 FILTER AS 3611901530 DWF-5590DPNF, E-TYPE PUMP
