PARTS DIAGRAM
§§
è
Parts List
LOC. PART NAME PART CODE SPECIFICATION REMARK
D01 COVER TUB O 3611414600 PP
D02 TUB O 3618807600 PP
D03 SUSPENSION AS F 3619802300 DWF-5510NP
D04 SUSPENSION AS B 3619802400 DWF-5510NP
D05 NOZZLE BODY 3618101400 PP
D06 HOSE DRAIN I 3613220600 TPE PUMP
D07 HOSE OVERFLOW 3613220700 L=245 N-PUMP
D08 VALVE DRAIN AS 3615404020 5591D, VE N-PUMP
D09 HOSE DRAIN I AS 3613221800 DWF-5510N N-PUMP
D10 BASE 3610302900 SECEN 1.6t
D11 SPECIAL BOLT BASE 4505E83100 6.5x23
D12 HARNESS SUB AS
3612754900 SUB HARNESS+EARTH PUMP
3612754910 SUB HARNESS+EARTH N-PUMP
D13 HOSE 4500D08220 ID=8, L=20 CAVITATION HOSE
D14 CLAMP 4500D08180 SWC BUBB PIE=8
D15 HOSE 4500D08220 ID=8, L=30 BUBBLE HOSE
D16 CLAMP 4500D08180 SWC BUBB PIE=8
D17
HARNESS EARTH INNER
3612755700 L=180 CHILE
3966010270 AC 220~240V/50Hz PUMP
3966010260 AC 220~240V/50Hz N-PUMP
3966320370 AC 220V/60Hz PUMP
D18
SYNCRONOUS MOTOR
3966320360 AC 220V/60Hz N-PUMP
450ED45170 AC 110~127V/60Hz PUMP
450ED45176 AC 110~127V/60Hz N-PUMP
3966130260 AC 100V/50,60Hz N-PUMP
D19 LINK BRAKE 3617801010 PP PUMP
D20 GEAR MECHANISM
3617306000 GM-4900-KJ4XO N-PUMP
3617306010 GM-4900-KJ4PO PUMP
D21 BOLT HEX 7640802011 6B-1 8x20 SW MFZN
D22 PROTECTOR GEAR 3618301300 SBHG 1.6t
D23 BELT V
4507D34020 M 20 50Hz
4507B34020 M19.5 60Hz
D24 SPECIAL WASHER 4505E34030 PP
3964340100 AC 220~240V/50Hz NP, N, MP, M
D25 MOTOR CONDENSER 3964340200 AC 220V/60Hz LP, L
3964340300 AC 10~127V/60Hz TP, T, SP, S
D26 SPECIAL WASHER 4505E34040 PP
D27 BOLT HEX 7650802511 6B-1 8X25 HS MFZN
D28 PULLY MOTOR AS
3618401420 M-TYPE DS=10 DP=53.0 50Hz
3618402800 M-TYPE DS=10 DP=48.5 60Hz
D29 HARNESS SUB AS
3612754900 SUB HARNESS + EARTH + PUMP PUMP
3612754910 SUB HARNESS + EARTH N-PUMP
To Next Page
